Juki HZL-DX5 Sewing & Quilting Machine

SKU: JUHZLDX5

$1,199.00

$1,199.00 ~~$1,999.00~~ 40% off

Product variants

Smooth, smart, and built for precision—perfect for quilting and sewing heavy fabrics.

Industrial-style Box Feed system for flawless fabric handling
Float Function prevents distortion on layered or bulky fabrics
Straight Stitch Slide Plate for lightweight or delicate fabric control
Automatic thread cut, lock, lift & reverse functions for seamless sewing

$1,999.00 $1,199.00

View full details

Juki HZL-DX5 Sewing and Quilting Machine

The Juki HZL-DX5 is a computerized sewing and quilting machine built around Juki's industrial box feed system. It handles heavy denim, layered quilts, and fine fabrics with consistent stitch quality and quiet operation.

Juki HZL-DX5 front view showing LCD display, keypad, and DX5 branding

Fabric Handling

The box feed system from Juki's industrial line moves fabric in a square motion for even feeding without shifting. A float function lifts the presser foot slightly (adjustable to 0.1mm) for bulky or layered fabrics to prevent distortion. The straight stitch slide plate switches to a single needle hole to prevent lightweight fabrics from being pulled into the feed dogs.

Juki box feed system diagram showing square feed dog motion for even fabric feeding

Industrial Box Feed System

Standard home machines move the feed dogs in an oval. The DX5's box feed moves them in a square, keeping the fabric in contact with the feed dogs longer for more consistent feeding. This makes the biggest difference on heavy materials, thick seams, and multiple layers where standard machines can slip or shift.

Key Features

Industrial box feed system for even fabric feeding
Float function adjustable to 0.1mm for bulky fabrics
Straight stitch slide plate for fine fabrics
Automatic thread trimming, reverse, and lock stitch
Automatic presser foot lift
LCD screen with direct pattern selection
Quiet operation

See the full Juki collection at Quality Sewing or compare with the Juki HZL-DX7.

Specifications

Key Specs	185 Built-in Stitches 16 Sensor Buttonholes 1,050 SPM Needle Threader: Automatic One-Hand Thread Cutter: Automatic Backlit LCD Display 8" Throat Space to the right of the needle 5 Presser Feet Included Box Feed System for Industrial Quality 5/1 Year Limited Warranty
Sewing Features	Built-in Stitches: 185 Max Sewing Speed: 1,050 stitches per minute (adjustable: fast, normal, slow) Max Stitch Width: 7mm (0.3 in.) Max Stitch Length: 5mm (0.2 in.) Buttonholes: 16 styles with sensor system Fonts: 3 alphabetic and numeric fonts
Threading & Bobbin	Thread Trimmer: Automatic (button or heel-activated) Needle System: 130R / 705H Bobbin Type: 15 Class
Workspace & Display	Knee Lifter: Included Weight: 21.6 lbs Dimensions: 17.5 x 11.5 x 8.25 in. (W x H x D)
Smart Features	Free Motion: Straight stitch and zig-zag with drop feed dogs Straight Stitch Slide Plate: Single needle hole plate for precision Lock Stitch: Two kinds of reverse stitch and lock stitch options Adjustable Starting and Reverse Stitch Speed
Included Feet	Presser Foot Lift: Electronic Presser Foot Pivot Function: Automatic foot lift when stopped for fabric repositioning Foot Pressure: Adjustable Shank Type: Low Included Feet: Standard, Zipper, Overcasting, Blind Stitch, Buttonhole, Manual Buttonhole, Walking Foot, Patchwork, Quilt
Included Accessories	Hard case 9 presser feet (Standard, Zipper, Overcasting, Blind Stitch, Buttonhole, Manual Buttonhole, Walking Foot, Patchwork, Quilt) Knee lifting lever Foot controller Bobbins Needle set Twin needle Quilt guide Auxiliary spool T-shape screwdriver Seam ripper Cleaning brush Spool cap Power cord Instruction manual Operations support DVD
Warranty	5-Year Limited Warranty on Head 1-Year Limited Warranty on Electronics 1-Year Quality Sewing Warranty
